| Processor |
1.0GHz NXP i.MX6 Quad/ Dual/ Dual Lite Cortex-A9 SoC |
| Memory |
2GB DDR3-1066 SDRAM onboard (Optional 4GB) |
| Storage |
8GB of eMMC memory (Optional 16GB) |
| OS |
Android 6.0, Linux 4.1.15, Yocto Project2.0 with QT 5.4 (Weston Wayland UI) |
| Display |
HDMI 1.4 port |
| Ethernet |
1 x RJ45-10/100/1000 Mbps |
| USB Port |
1 x mini USB 2.0 (OTG) Type B &3 x USB 2.0 Type A |
| COM Port |
1 x COM1 (supports 5-wire TX/RX/RTS/CTS) RS232/RS485/RS422 |
| CAN BUS |
1 x D-SUB 9 Connector with CAN BUS |
| LED |
1 x Power LED & WIFI LED (if Wi-Fi has installed) |
| GPIO |
1 x DIO Port support 8 GPIOS |
| SD Slot |
1 x Micro SD/SDHC card slot |
| Power Jack |
1 x Power Jack DC+12V |
| PoE |
Supports PoE (Optional), Power Device(PD): follows IEEE 802.3af (12.5W) (option) |
| WIFI / BT |
Wi-Fi module (option) |
| Audio |
Audio Combo Header, (Mic_in,Line_out) |
| Operating Temperature |
Commercial version: 0℃ to 60℃, Industrial version :-20℃ to 60℃ |
| Operating Humidity |
10% to 90% (non-condensing) |
| Cooling System |
Fanless design |
| Dimension ( L x W x H) |
143mm x 74mm x 60mm (w/o antenna) |
