| Processor |
1.0GHz NXP i.MX6 Quad/ Dual/ Dual Lite Cortex-A9 SoC |
| Memory |
2GB DDR3-1066 SDRAM onboard (Optional 4GB) |
| Storage |
8GB of eMMC memory (Optional 16GB) |
| OS |
Android 6.0, Linux 4.1.15, Yocto Project2.0 with QT 5.4 (Weston Wayland UI) |
| Interface |
LVDS, HDMI |
| Ethernet |
1 x RJ45-10/100/1000 Mbps |
| HDMI |
1 x HDMI® 1.4 port |
| COM Port |
1 x COM1 (supports 5-wire TX/RX/RTS/CTS) RS232 DTE mode/RS485/RS422 |
| USB Port |
1 x USB 3.0(OTG) Type B & 1 x USB 2.0 Type A |
| LED |
1 x Power LED & WIFI LED (if Wi-Fi has installed) |
| SD Slot |
1 x Micro SD/SDHC card slot |
| Boot Select Switch |
1 x Micro SD/eMMC boot select switch |
| Reset |
1 x Reset Button |
| Power Jack |
1 x Power Jack |
| PoE |
Supports PoE (Optional), Power Device(PD): follows IEEE 802.3af (12.5W) |
| WIFI / BT |
Wi-Fi module (Optional) |
| Audio |
Audio Audio Combo Header, (Mic_in,Line_out, Spk_out, HP_out, SPDIF) |
| MIPI-CSI |
MIPI-CSI, ZIF connector |
| Backlight Control |
LCD Backlight control wafer |
| PCAP |
PCAP touch panel wafer |
| USB |
1 x USB 2.0 expansion header |
| Interface |
multi-role, keypad, GPIOs |
| UART |
1 x UART2 wafer |
| Operating Temperature |
Commercial version: 0℃ to 60℃, Industrial version :-20℃ to 60℃ |
| Operating Humidity |
10% to 90% (non-condensing) |
| Cooling System |
Fanless design |
| Dimension ( L x W) |
110mm x 70mm |
| Power Input |
12V |
| Power Over Ethernet |
Supports PoE (Optional), Power Device(PD): follows IEEE 802.3af ( 12.5W) |
