| Processor |
Dual Cortex-A72 @2.0Ghz + Quad Cortex-A53 @ 1.5Ghz |
| Multi-Media Processor |
ARM Mail-T860MP4 (GPU), AFBC supported |
| Multi-Media Processor |
Provides OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11 |
| Multi-Media Processor |
Video Decoder: H.264/H.265, 10bit, up to 4Kx2K@60fps, VP9, 8bit, up to 4Kx2K@60fps, MPEG-4/MPEG-2/VP8 up to 1080p@60fps |
| Multi-Media Processor |
Video Encoder: H.264/MVC/VP8 encoders by 1080p@30fps |
| Memory |
2GB DDR3-1066 SDRAM onboard (Optional 4GB) |
| Storage |
8GB of eMMC memory ( Optional 16 GB)/ Micro SD |
| OS |
Android 7.1, Linux(Debian 9.0) |
| Interface |
eDP, LVDS, HDMI |
| Ethernet |
1 x RJ45-10/100/1000 Mbps |
| HDMI |
1 x HDMI® V2.0 Type A, 4Kx2K @60fps, HDCP2.x |
| eDP |
1 x eDP 1.3, 2 lane , 1080p@60fps, ZIF |
| LVDS |
drive with FR2136 board |
| USB Port |
1 x USB 3.0(OTG) Type & 1 x USB 2.0 Type A |
| SD Slot |
1 x Micro SD/SDHC card slot |
| Power Jack |
1 x Power Jack |
| PoE |
Supports PoE (Optional), Power Device(PD): follows IEEE 802.3at (25W) |
| WIFI / BT |
WLAN, 802.11 (a/b/g/n/ac, 2Tx2R) + Bluetooth (4.1 LE) |
| Audio |
Audio Combo Header, (Mic_in,Line_out, Spk_out, HP_out, SPDIF) |
| MIPI-CSI |
MIPI-CSI, ZIF connector |
| Backlight Control |
LCD Backlight control wafer |
| PCAP |
PCAP touch panel wafer |
| USB |
3 x USB 2.0 expansion header |
| Interface |
multi-role, keypad, GPIOs |
| MEMS |
MEMS Combo header |
| UART |
RS232 console wafer |
| Operating Temperature |
Commercial version: 0℃ to 60℃, Industrial version :-20℃ to 60℃ |
| Operating Humidity |
10% to 90% (non-condensing) |
| Cooling System |
Fanless design |
| Dimension ( L x W) |
126.5mm x 90mm |
| Power Input |
12V |
| Power Over Ethernet |
Supports PoE (Optional), Power Device(PD): follows IEEE 802.3at ( 25W) |
